Levo^® C3 standing power wheelchair

Code(s): 0400-0010, 0400-0020, 0400-0030, 0400-0050

This powered wheelchair is highly configurable, with many different options, colours and sizes available. Get in touch with our friendly team so we can help you meet your clients' requirements.

The Levo C3 is the ultimate powered standing wheelchair, perfect for active people on the move. The C3 drive system turns a maneuverable mid-wheelbase into a powerful, curb climbing 4-wheel drive action base, offering a brilliant turning circle. Integrated with the latest advancements in the renowned Levo standing systems, this powered wheelchair ensures an incredibly smooth transition to standing, while the automatic wheelbase adjustment means you have a front wheel drive base for unmatched stability.

Quantity

Key features

Four powered wheels for superior traction and agility
Climbs over curbs up to 4 inches
Safely and effectively climbs and descends ramps up to 10˚
Off road traction capability
Multiple programming options
Solid, secure and safe brake action
Low shearing system during transition to standing
Engineered chairs and biomechanics in all seating and standing positions
Low seat height for transfer and driving under tables
Easily adjusted to individual body measurements
Power elevating legrest
Low shear back support
Easily adapts to any back support
Maximum safety in all positions
Compact maneuverability for tight spaces
High battery capacity
Highly configurable to suit individual needs
Different colour and size options available

Seat function:

Tilt or Multifunction

Drive configuration:

4WD

Seat width:

12.5", 14", 16", 17", 19", 20.5"

Seat depth:

14" - 25"

Base width (wheelbase):

24.8"

Base length (wheelbase):

43.3"

Seat-to-floor height:

19" or 21"

Turning radius:

46"

Max. user weight:

140kg

Battery capacity:

48Ah (73Ah option)

Tilt range (up to):

35°

Backrest recline (range):

40°

Drive wheel size:

14"

Castor size:

Motor type:

4-pole

Base unit weight (incl battery):

185kg

Speed:

6, 8 or 10km/h

Backrest height:

16.1"

Seat height:

18.9" or 21.3"

Armrest height:

5.9" - 14.2"

Total height:

39.4"

Maximum curb climbing:

100mm

Maximum safe slope:

10°

Range - 73 Ah batteries:

35km

Range - 48 Ah batteries:

25km

Specifications

Code(s)	0400-0010	0400-0020	0400-0030	0400-0050
Option	Tilt/400mm	Tilt/480mm	Multifunction/400mm	Multifunction/480mm
Seat function	Tilt or Multifunction	Tilt or Multifunction	Tilt or Multifunction	Tilt or Multifunction
Drive configuration	4WD	4WD	4WD	4WD
Seat width	12.5", 14", 16", 17", 19", 20.5"	12.5", 14", 16", 17", 19", 20.5"	12.5", 14", 16", 17", 19", 20.5"	12.5", 14", 16", 17", 19", 20.5"
Seat depth	14" - 25"	14" - 25"	14" - 25"	14" - 25"
Base width (wheelbase)	24.8"	24.8"	24.8"	24.8"
Base length (wheelbase)	43.3"	43.3"	43.3"	43.3"
Seat-to-floor height	19" or 21"	19" or 21"	19" or 21"	19" or 21"
Turning radius	46"	46"	46"	46"
Max. user weight	140kg	140kg	140kg	140kg
Battery capacity	48Ah (73Ah option)	48Ah (73Ah option)	48Ah (73Ah option)	48Ah (73Ah option)
Tilt range (up to)	35°	35°	35°	35°
Backrest recline (range)	40°	40°	40°	40°
Drive wheel size	14"	14"	14"	14"
Castor size	8"	8"	8"	8"
Motor type	4-pole	4-pole	4-pole	4-pole
Base unit weight (incl battery)	185kg	185kg	185kg	185kg
Speed	6, 8 or 10km/h	6, 8 or 10km/h	6, 8 or 10km/h	6, 8 or 10km/h
Backrest height	16.1"	16.1"	16.1"	16.1"
Seat height	18.9" or 21.3"	18.9" or 21.3"	18.9" or 21.3"	18.9" or 21.3"
Armrest height	5.9" - 14.2"	5.9" - 14.2"	5.9" - 14.2"	5.9" - 14.2"
Total height	39.4"	39.4"	39.4"	39.4"
Maximum curb climbing	100mm	100mm	100mm	100mm
Maximum safe slope	10°	10°	10°	10°
Range - 73 Ah batteries	35km	35km	35km	35km
Range - 48 Ah batteries	25km	25km	25km	25km
